Products Description
Wastewater treatment using air blower oil free blower with IE3
motor
Improt HS CODE: 8414100090
- Product description: 1.Designed and improved by the latest Europe
technology,Molded with high strength,ADC12 aluminum alloy,Processed
on precision CNC machine. 2.Two- pole motor with TEFC IP54 and
insulation F,high tempe
Technical details
| Model No. | GHBH 003 34 1R3 |
| Phase | single |
| Stage | single |
| Frequency | 50HZ | 60HZ |
| Output | 0.7kw | 0.83kw |
| Voltage | 200-240△ |
| 220-275△ |
| Current | 4.5 | 5.6 |
| Max Airflow | 100m3/h | 120m3/h |
| Max Vacuum | 150mbar | 160mbar |
| Max Pressure | 170mbar | 180mbar |
| Gloss Weight | 13kgs |
| Speed of rotation | 2850/3450r/min |
| Sound | 57/60db |
| Level of protection | IP54 |
| Insulation class | F |
Unit price:USD50-80/SET ( Can be discussed with sales )Business Terms
- MOQ: 1 Set
- Delivery time: 3-10days
- Payment terms: by TT, 100% before delivery or 30% deposit, 70%
balance against copy of BL.
- Delivery terms: EX-WORK, CIF, FOB, DDP, DDU is available;
After-sales service
When the blower has been risen for a problem, we need the customer
provide following data sheet:
Firstly, we need the clear pictures of the blower, also the working
site pictures, and the description details of the problem.
Secondly, we will feedback the information to our engineer to check
and find a diagnosis to the problem.
If the problem is a small quality problem itself, then we will send
repair instruction to you to fix, if any accessories broken, we
will send the new accessories to you, also, we would consider
sending a new blower to you depends on the situation.
If the problem was caused by customers' improper use of blowers, we
will also offer you instruction how to repair it. And if need the
accessories, we also supply the accessories to you with charges.
Warranty terms
Within 3 months, send a free brand-new blower while ocean
freight/express courier is on customer's account.
Within 24months sending instruction via email and give a diagnosis
to the problem. Then send free accessories while express rate is on
customer’s account.
Applications
Goorui blower has been widely used in more than 100 different
applications. It can be used for vacuum propose, such as printing
machine, dental suction machine,vacuum cleaner, central vacuum
system,air knife system, drying machine,PCB drying machine, CNC
router, vacuum lifting,etc;
Or it can be used for pressure propose, such as water,waste water
treatment, spa aeration, aquaculture, bio-gas conveying,oil
treatment equipment,Gas analysis, Smoke extraction
equipment,Milking equipment,Bottling equipment,Feeding
machine,TEXTILE machine,etc;
