    400 W Goorui Side Channel Vacuum Pump Blower In Cnc , Air Suction Blower

    Ask Lasest Price
    Brand Name : GOORUI
    Model Number : GHBH 0D5 34 1R2 400W
    Certification : CE/TUV/ISO9001-2001/SGS/ROHS
    Price : Negotiable
    Payment Terms : T/T, L/C,
    Supply Ability : 3000 sets per month
    Delivery Time : 10-15 working days.depends on order amount and specification
    • Product Details
    • Company Profile

    400 W Goorui Side Channel Vacuum Pump Blower In Cnc , Air Suction Blower


    400 W Goorui Side Channel Vacuum Pump Blower In Cnc , Air Suction Blower



    ModelGHBH 0D5 34 1R2
    PhaseThree
    StageSingle
    Frequency50HZ60HZ
    Output0.4kw0.5kw
    Voltage200-240△/345-415Y220-275△/380-480Y
    Current2.6△/1.5Y2.6△/1.5Y
    Max Airflow80m3/h98m3/h
    Max Vacuum-120mbar-150mbar
    Max Pressure130mbar160mbar
    Gross Weight10kgs
    Sound53/56db
    Level of protectionIP55

    BLOWER PERFORMANCE CURVES:

    Goorui Ring Bower feathers and advantages :

    • Oil free and low noise
    • No routine maintenance with stable performance
    • Easy install and no vibration
    • Either used for suction ( vacuum ) or discharge ( pressure )
    • Insulation class: F, Protection class: IP54
    • Wide voltage & frequency range 28-60hz
    • Air flow range: 45 - 2330 m3/h (50/60 Hz)
    • Pressure range: 80mbar to 1040 mbar
    • Vacuum range: -70mbar to -730 mbar
    • Insulation class: F/H
    • Protection class: IP54/IP55
    • CCC, CE, RoHs, SGS, ISO9001-2008 certification


    GOORUI Ring Blower applications:
    • Agriculture(Fish pond and aeration tanks)
    • Beverage(bottle drying)
    • Bio fuels/bio-gas system
    • Food and vegetable processing
    • Medical and Health service(Dental cart and dental vacuum)
    • Package (Air knives blown-off / Labeling/Drying)
    • Plastics/Rubber(Air knives blown-off/ Bottle blow moulding/ Extruder Degassing/Pneumatic conveying/ Thermoforming)
    • Printing
    • Paper and pulp/ paper converting
    • Textile industry
    • Transportation/Loading/Unloading(Pneumatic conveying/material handling)
    • Water treatment/sewage treatment
    • Woodworking(CNC Routing/bulk handling

    Application picture:



    Delivery time :

    In stock blower: 2-3days after payment
    Out of stock blower:7-15days after order confirmed.
    Special blower need to check specific

    We keep more than 1000sets blower regularly in stock to satisfy your fast delivery demands.
