IE3 Motor 25HP High Pressure Air Blower for Material Conveying System

    Buy cheap IE3 Motor 25HP High Pressure Air Blower for Material Conveying System from wholesalers

    Buy cheap IE3 Motor 25HP High Pressure Air Blower for Material Conveying System from wholesalers
    • Buy cheap IE3 Motor 25HP High Pressure Air Blower for Material Conveying System from wholesalers

    IE3 Motor 25HP High Pressure Air Blower for Material Conveying System

    Ask Lasest Price
    Brand Name : GOORUI
    Model Number : GHBH 025 36 1R9 IE3
    Certification : CE/TUV/ISO9001-2001/SGS/ROHS
    Price : Negotiable
    Payment Terms : T/T, L/C, D/P
    Supply Ability : 3000 sets per month
    Delivery Time : 7-10 working days.
    • Product Details
    • Company Profile

    IE3 Motor 25HP High Pressure Air Blower for Material Conveying System


    IE3 motor IP55 25hp Side Channel Air Blower for Vacuum Conveying


    ModelGHBH 025 36 1r9
    PhaseThree
    StageSingle
    Frequency50HZ60HZ
    Output18.5kw21.3kw
    Voltage345-415△/600-690380-480△/660-720
    Current37.0/21.039.0/22.5
    Max Airflow1050m3/h1250m3/h
    Max Vacuum-360mbar-380mbar
    Max Pressure460mbar420mbar
    Gross Weight126kgs
    Speed of rotation2850/3450r/min
    Sound74/79db
    Level of protectionIP55
    Insulation classF


    GOORUI Side Channel Blower applications:
    • Agriculture(Fish pond and aeration tanks)
    • Beverage(bottle drying)
    • Bio fuels/bio-gas system
    • Food and vegetable processing
    • Medical and Health service(Dental cart and dental vacuum)
    • Package (Air knives blown-off / Labeling/Drying)
    • Printing
    • Paper and pulp/ paper converting
    • Textile industry
    • Pneumatic conveying/material handling
    • Water treatment/sewage treatment
    • Woodworking(CNC Routing/bulk handling


    Goorui Bower feathers and advantages :

    • Oil free and low noise
    • Insulation class: F/H
    • Protection class: IP54/IP55
    • No routine maintenance with stable performance
    • Easy install and no vibration
    • SKF , NSK , ORS bearing adapt to ensure long-life time
    • Either used for suction ( vacuum ) or discharge ( pressure )
    • Insulation class: F, Protection class: IP54
    • Wide voltage & frequency range 28-60hz
    • Air flow range: 45 - 2330 m3/h (50/60 Hz)
    • Pressure range: 80mbar to 1040 mbar
    • Vacuum range: -70mbar to -730 mbar
    • CCC, CE, RoHs, SGS, ISO9001-2008 certification


    Delivery time :


    • In stock blower: 2-3 days after payment
    • Out of stock blower:7-15 days after order confirmed.
    • Special customized blower based on the specific request.

    We keep more than 2000sets blower regularly in stock to satisfy your fast delivery demands.
